Model: HL105AH Code: 086500316516
| Refrigerant: | R600a |
| Application: | LBP |
| Evaporating Temperature Range: | -30°C to -10°C |
| Voltage/Frequency: | 220/240V/50 HZ |
| Compressor Cooling: | Static |
| Expansion Device: | Capillary Tube |
| Packaging Quantity: | Multi - 96:120 pcs |
| Approvals: | CE |
| Oil Charge: | 160 cm3 |
| Oil Type Configuration: | Mineral |
| Oil Type Viscosity: | 5 cSt |
| Weight: | 7.6 kg |
| Motor Type: | RSCR |
| Voltage working range at 50 Hz: | 187-264V |
| Maximum Motor Temperature: | 130°C |
| Start Winding Resistance: | 25.1 Ω at 25°C |
| Run Winding Resistance: | 18.50Ω at 25°C |
| Phase: | 1 ph |
| Internal Diameter | (mm) |
| Suction Connector | 6.55 |
| Discharge Connector | 4.9 |
| Process Connector | 6.55 |
| Material | Copper |
| Starting Device: | PTC QP2-15Ω |
| Motor Protection: | DRB24P61A1 |
