Compressor Technical Data

Model: EGM35AF       Code: 500540314416

General Data

Refrigerant: R134a
Application: LBP
Evaporating Temperature Range: -30°C to -10°C
Voltage/Frequency: 220/240V/(50-60) HZ
Compressor Cooling: Static
Expansion Device: Capillary Tube
Packaging Quantity: Multi - 96:120 pcs
Approvals: CE-GOST

Mechanical Data

Oil Charge: 130 cm3
Oil Type Configuration: ester
Oil Type Viscosity: 19 cSt
Weight: 4.5 kg

Electrical Data

Motor Type: RSIR / RSCR
Voltage working range at 50 Hz: 187-240V
Maximum Motor Temperature: 130°C
Locked Rotor Current: 5.5A
Start Winding Resistance: 21.5 Ω at 25°C
Run Winding Resistance: 41.00 Ω at 25°C
Phase: 1 ph

External Characteristics

Internal Diameter (mm)
Suction Connector 6.55
Discharge Connector 4.9
Process Connector 6.55
Material Copper

Electrical Components

Starting Device: PTC 15 Ω
Motor Protection: DRB17P61A1
