Compressor Technical Data

Model: GP12FB       Code: 354000322016

General Data

Refrigerant: R134a
Application: LBP
Evaporating Temperature Range: - 35°C to -10 °C
Voltage/Frequency: 220/240V/50 HZ
Compressor Cooling: Static
Expansion Device: Capillary Tube
Packaging Quantity: Multi - 96:120 pcs
Approvals: CE-VDE

Mechanical Data

Oil Charge: 400cm3
Oil Type Configuration: ester
Oil Type Viscosity: 19 cSt
Weight: 11.00 kg

Electrical Data

Motor Type: CSIR
Voltage working range at 50 Hz: 198/264V
Maximum Motor Temperature: 130°C
Locked Rotor Current: 14.0 A
Start Winding Resistance: 33.95 Ω at 25°C
Run Winding Resistance: 7.45Ω at 25°C
Phase: 1 ph

External Characteristics

Internal Diameter (mm)
Suction Connector 8.1
Discharge Connector 6.55
Process Connector 8.1
Material Copper

Electrical Components

Component Type Relay MTRP4327
Starting Device: T0138/xx
Motor Protection: 47/56 µF/250v
Owl Image

Assembly instructions for Terminal board

Download

External View

Download
