Compressor Technical Data

Model: GL45AN       Code: 402070326316

General Data

Refrigerant: R134a
Application: LBP
Evaporating Temperature Range: - 30°C to -10°C
Voltage/Frequency: 200/240V – 220/230 V/(50-60) HZ
Compressor Cooling: Static
Expansion Device: Capillary Tube
Packaging Quantity: Multi - 96:120 pcs
Approvals: CE-VDE

Mechanical Data

Oil Charge: 265 cm3
Oil Type Configuration: ester
Oil Type Viscosity: 19 cSt
Weight: 9 kg

Electrical Data

Motor Type: RSIR
Voltage working range at 50 Hz: 170-264V /187-253V
Maximum Motor Temperature: 130°C
Locked Rotor Current: 12.2 / 6.0 A** - 11.1 / 5.5 A**
Start Winding Resistance: 21.90 Ω at 25°C
Run Winding Resistance: 13.00 Ω at 25°C
Phase: 1 ph

External Characteristics

Internal Diameter (mm)
Suction Connector 6.5
Discharge Connector 4.9
Process Connector 6.5
Material Copper

Electrical Components

Starting Device: PTC 14Ω
Motor Protection: T0508/xx
Owl Image

Assembly instructions for Terminal board

Download

External View

Download
