Model: EGM45AF Code: 502500312816
Refrigerant: | R134a |
Application: | LBP |
Evaporating Temperature Range: | -30°C to -10°C |
Voltage/Frequency: | 220/240V/50 HZ |
Compressor Cooling: | Static |
Expansion Device: | Capillary Tube |
Packaging Quantity: | Multi - 96:120 pcs |
Approvals: | CE-VDE-GOST |
Oil Charge: | 270 cm3 |
Oil Type Configuration: | ester |
Oil Type Viscosity: | 19 cSt |
Weight: | 8.5 kg |
Motor Type: | RSIR |
Voltage working range at 50 Hz: | 187-264 V |
Maximum Motor Temperature: | 130°C |
Locked Rotor Current: | 9.47 / 4.56 A |
Start Winding Resistance: | 23.00 Ω at 25°C |
Run Winding Resistance: | 24.30 Ω at 25°C |
Phase: | 1 ph |
Internal Diameter | (mm) |
Suction Connector | 6.5 |
Discharge Connector | 4.9 |
Process Connector | 6.5 |
Material | Copper |
Starting Device: | PTC 14 Ω |
Motor Protection: | T0500/xx |
