Compressor Technical Data

Model: HL80AH       Code: 082040316416

General Data

Refrigerant: R600a
Application: LBP
Evaporating Temperature Range: -30°C to -10°C
Voltage/Frequency: 220/240V/50 HZ
Compressor Cooling: Static
Expansion Device: Capillary Tube
Packaging Quantity: Multi - 96:120 pcs
Approvals: CE

Mechanical Data

Oil Charge: 160 cm3
Oil Type Configuration: Mineral
Oil Type Viscosity: 5 cSt
Weight: 7.4 kg

Electrical Data

Motor Type: RSCR
Voltage working range at 50 Hz: 187-264V
Maximum Motor Temperature: 130°C
Start Winding Resistance: 24 Ω at 25°C
Run Winding Resistance: 26.6 Ω at 25°C
Phase: 1 ph

External Characteristics

Internal Diameter (mm)
Suction Connector 6.55
Discharge Connector 4.9
Process Connector 6.55
Material Copper

Electrical Components

Starting Device: PTC QP2-15Ω
Motor Protection: DRB20P61A1
Owl Image

Assembly instructions for Terminal board

Download

External View

Download
