Compressor Technical Data

Model: EGM50AF       Code: 503500313016

General Data

Refrigerant: R134a
Application: LBP
Evaporating Temperature Range: -30°C to -10°C
Voltage/Frequency: 220/240V/50 HZ
Compressor Cooling: Static
Expansion Device: Capillary Tube
Packaging Quantity: Multi - 96:120 pcs
Approvals: CE-VDE-GOST

Mechanical Data

Oil Charge: 270 cm3
Oil Type Configuration: ester
Oil Type Viscosity: 19 cSt
Weight: 8.4 kg

Electrical Data

Motor Type: RSIR
Voltage working range at 50 Hz: 187-264 V
Maximum Motor Temperature: 130°C
Locked Rotor Current: 10.24 / 5.22 A
Start Winding Resistance: 22.20 Ω at 25°C
Run Winding Resistance: 20.40 Ω at 25°C
Phase: 1 ph

External Characteristics

Internal Diameter (mm)
Suction Connector 6.5
Discharge Connector 4.9
Process Connector 6.5
Material Copper

Electrical Components

Starting Device: PTC 14 Ω
Motor Protection: T0500/xx
Owl Image

Assembly instructions for Terminal board

Download

External View

Download
